29” WHEELS, ALL-ROUND
|
ACTIVE - INDEPENDENT FLOATING SUSPENSION Polygon’s all-new 6-bar IFS linkage provides 160mm of optimised wheel path to swallow square-edge hits and remain active under braking, while the independent shock leverage allows unrivalled sensitivity with progressive support for composure in the rowdiest of rock gardens. |
GEOMETRY - SLACK, LONG & LOW Mt Bromo N features a slack 64.5° head angle with long reach and low bottom bracket. Combined with the 29” wheels and short offset fork for a long trail, the stability and high-speed composure is confidence inspiring. |
![]() |
![]() |
![]() |
EFFICIENT - INDEPENDENT FLOATING SUSPENSION The IFS platform’s separation of wheel path from shock leverage allows unbelievably efficient power transfer without sacrificing small bump compliance. Put your power down and Shimano STEPS delivers a mountain more, direct to the ground on even the chunkiest trails. |
BALANCE OF FUN
|
GEOMETRY - STEEP, SHORT & LOW Rip around corners, manual off technical drops and place your wheels with precision; agility is achieved by one of the shortest rear centre lengths in category, possible thanks to the IFS vertical wheel path and elevated chainstay design. Despite the 435mm rear centre, you’ll confidently conquer the steepest climbs thanks to the steep 77° seat angle and low, forward centre of gravity. |
![]() |
![]() |
![]() |
POWER WITH PRECISIONShimano STEPS e-MTB drive systems provide 4 power modes; Eco, Trail, Boost, and Walk-Assist. Shimano’s E-TUBE PROJECT app lets you customize the assistance of each mode to your personal preferences. |
INTEGRATED LIGHTWEIGHT BATTERYThe fully integrated BT-E8035 504Wh battery clicks seamlessly in the downtube. It’s far lighter than larger batteries for improved agility while packing enough fast-charging capacity for big adventures. |
HIGH TECH DRIVETRAINThe perfect pairing with Shimano STEPS drive systems, Mt Bromo N’s Shimano XT 1x12 HYPERGLIDE+ drivetrains deliver smooth and consistent shifts, even under load, over the wide 510% gear range. |
ALX ENDURO FRAME |
|
Fork |
FOX 38 FLOAT PERFORMANCE FIT GRIP 160MM, 44MM OFFSET |
Rear Shock |
FOX X2 FLOAT, E2E: 205x65MM |
Head Set |
ZERO STACK THREADLESS, ZS 44/28.6 | ZS 56/40 |
Stem |
ENTITY EXPERT ALLOY, EXT: 35MM, BARBORE: 35MM |
Handlebar |
ENTITY EXPERT ALLOY, W: 780MM, BARBORE: 35MM, RISE: 25MM, BEND: 9DEGREE |
Rear Derailleur |
SHIMANO DEORE XT RD-M8100 1x12 |
Shifter |
SHIMANO DEORE XT SL-M8100 1x12 TRIGGER |
Drive Unit |
Shimano EP8 85Nm 504Wh battery |
Crank Set |
E13 E-SPEC PLUS CRANK, 165MM, 34T, DIRECT MOUNT |
Cassette |
SHIMANO CS-M6100 10-51T |
Chain |
SHIMANO CN-M6100 |
Pedal |
FLAT ALLOY W/ REPLACEABLE PIN |
Brake |
SHIMANO DEORE XT M8120 4-PISTON, 203MM ROTORS |
Wheel Set |
ENTITY XL2 35MM TLR RIMS, SHIMANO DEORE XT HUBS |
Tire |
SCHWALBE MAGIC MARY 29x2.6 EVO SUPER GRAVITY ADDIX SOFT |
Saddle |
ENTITY XTENT CR-MO ø7mm |
Seat Post |
TRANZ X JD-YSP23JL 150MM (S-M) / 170MM (L-XL) |
Wheel Size |
29" |
Color |
WHITE-BLACK |
