Rocky Mountain Altitude Powerplay A 70
2023malli
VAHVA SUOSITUS HENKILÖKUNNALTA .
- 720 Wh irroitettava Li-Ion -akku
- Dyname 4.0 Mountain Bike Drive -moottori
- 108Nm vääntöä
- Rengaskoko 29 tuumaa
- Alumiinirunko
- 170mm etujousto
- Shimano XT vaihteisto
DESIGNED FOR | WHEEL SIZE | FRONT TRAVEL | REAR TRAVEL |
Enduro ⚡ | 29" | 170 mm |
160 mm |
|
|
|
|
Slim and simple E-bike controls A simple and low-key top-tube display mount keeps you in the know at all times. Battery, assistance level, adjustability. It’s right where you need it, and it’s outta harm’s way. |
Dyname 4.0 drive system TORQUE 108 Nm MAX POWER OUTPUT 700 W MAX BOOST 350% |
BATTERY CAPACITY 720 Wh |
Micro Remote |
SPECIFICATIONS | ALTITUDE POWERPLAY ALLOY 70 |
---|---|
Frame | FORM™ Alloy. Integrated Display. Mid-High Pivot Smoothlink Suspension System. Press Fit BB. RIDE-4™ Adjustable Geometry + Suspension Rate. 160mm Travel. FORM™ Alloy Rear Triangle |
Fork | Fox 38 Float EVOL GRIP Performance Series 170mm | 44mm Offset |
Front Travel | 170mm |
Shock | Fox Float X Performance | Sealed Bearing Eyelet | 25x8mm F Hardware | All Sizes = 230×62.5mm | Size-Specific tune in FAQ |
Rear Travel | 160mm |
Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5″ Crown Race |
Stem | Rocky Mountain 35 AM | 5° Rise | All Sizes = 40m |
Handlebar | Rocky Mountain AM | 780mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp |
Grips | ODI Elite Pro Lock On |
Brakes | Shimano XT Trail 4 Piston | Metal Pads | F:Shimano RT66 203mm | R: Shimano RT66 203mm |
Shifters | Shimano XT |
Rear Derailleur | Shimano XT |
Cranks & Chainring | Race Face Aeffect Cinch 34T | 24mm Spindle | Crank Length: SM – MD = 165mm | LG – XL = 170mm |
Bottom Bracket | FSA BB89.5 24mm |
Cassette | Shimano Deore 10-51T 12spd |
Chain | Shimano M6100 |
Front Hub | Rocky Mountain Sealed Boost 15mm |
Rear Hub | DT Swiss Hybrid 370 Boost 148mm | 24T Star-Ratchet |
Spokes | F : DT Swiss Champion 2.0 | R : DT Swiss Alpine 2.3/2.0 |
Rims | WTB ST i30 TCS 2.0 Tubeless | 32H | Tubeless Ready – Tape | Valves Incl |
Tires | F: Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready | R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready | Cushcore XC Tire Inserts |
Seatpost | Race Face Aeffect R Dropper 30.9mm | Shimano MT500 Remote | SM = 125mm | MD = 150mm | LG – XL = 175mm |
Saddle | WTB Volt Race 142 |
Drive System | Dyname 4.0 Mountain Bike Drive | 250w Nominal Power | 700w Peak Power | 108Nm | Rocky Mountain Micro Remote | Low RPM – High Efficiency Classe 1 eMTB System | Designed in Canada |
Battery | 720 Wh Removable Integrated Li-Ion | xxx g |
Remote | Rocky Mountain Micro Remote |
Display | Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration |
Our new generation Powerplay lineup features massive 720wh capacity batteries, and they’re easily removable.
The Powerplay is about riding not sitting next to a power outlet, and our 4-amp charger quickly refuels the battery from empty to a full charge in 3 hours and 55 minutes, encouraging you to get back out there.
SIZING CHART | |
---|---|
SM | 157.5 – 170 cm |
MD | 167.5 – 177.5 cm |
LG | 175 – 188 cm |
XL | 185.5 – 198 cm |
